System: GEN4 proximity; the guide references Philips 46.
Factory tool: MicroPod with wiTECH.
PIN: Required.
Cloning: No cloning for this system.
Listed supported programmer: Smart Pro.
Verify support before use: T-Code/MVP Pro, TDB1000, Hotwire, Auto Pro Pad, and Autel IM608.
2018+ note: Some vehicles require a Gateway bypass cable to program proximity remotes.
Reuse note: The guide states 2011–2018 units are reusable; later units are not reusable.
Recommended Ways to Make a Key
Use a lock decoder/reader to decode the door lock for a working mechanical key.
Use an appropriate automotive tryout-key set, such as Baxter Systems set 97 All Locks or Aero Lock T0-93.
Remove a door or trunk cylinder and decode it; once the seven cuts are known, cut and verify the working key.
Professional service note: Programming requires compatible equipment and the vehicle PIN. Verify current programmer coverage and security-gateway requirements before service.
Tumbler Diagram
Ignition
Doors
Trunk
No.
1
2
3
4
5
6
7
8
